New Holland 480FI Forage Headers Service Manual (84539587A)

Illustrated factory Service Manual for New Holland Forage Headers Models 480FI.

This manual will assist you in diagnosing, analyses, testing, and repair for your forage header.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   480FI

Format: PDF, 232 pages
Language: English
Table of Contents:
   Safety
      Safety Measures
   General Information
      Identification View and Description
      Lubricants, Gear Oil and Coolant
      Torques
      Capacities
      Specifications
   Electrical System
      General
   Power Train
      Gear Box
      Friction Clutches
      Transmission - Feed Drums
      Transmission - Inner Gathering Drums
      Transmission - Outer Gathering Drums
      U-Jointed Shaft
   Hydraulic System
      Hydraulic System
   Miscellaneous
      Outer Folding Sections
   Feed System
      Inner Gathering Drums
      Outer Gathering Drums
      Rotors
      Feed Drums
   Diagnosing Malfunctions
      Troubleshooting
   Special Tools
      Special Tools (Dealer-Fabricated)
      Special Tools (Available as Spare Parts)
