Waratah HTH626 Harvesting Heads Component Technical Manual (CTM10005)

Illustrated factory Component Technical Manual for Waratah Harvesting Heads Models HTH626.

This manual will assist you in diagnosing, assembling, disassembling, and repairing for your harvesting head.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   HTH626

Format: PDF, 405 pages
Language: English
Publication Date: 06 Apr 2017
Table of Contents:
   Introduction
      Foreword
      Technical Information Feedback Form
   General Information
      Safety Instructions
      General Precautions
      Label Precautions
      Maintenance Precautions
      General Maintenance
      Miscellaneous Machine
   Tests and Diagnostics
      Test Points
      Cartridge Control
      Settings
      Hydraulic Schematic
      Harvester Head Module (HHM)
   Electric System
      Electric Control System-TimberRite
      Electric Control System-TR100
      TR100 Diagnostic Code Version V0.4.08
      TR100 Measuring System Diagnostic Codes Version V1.0.02
   Repair and Replacement
      Rotator
      Tilt Unit
      Upper Delimb Knives
      Top Knife
      Measuring System
      Fixed Feed
      Feed Arms
      Top Saw
      3/4 Main Saw
      Saw Chain and Saw Bar
      Accumulator
      Photocell Sensor
      Find-end Laser Sensor
      Control Valve
      Boom Cable
