Kawasaki FH451V, FH500V, FH531V, FH541V, FH580V, FH601V, FH641V, FH661V, FH680V, FH721V Gas.Engines Service Manual (KW-99924-2078-01)

Illustrated factory Service Manual for Kawasaki Gasoline Engines Models FH451V, FH500V, FH531V, FH541V, FH580V, FH601V, FH641V, FH661V, FH680V and FH721V.

This manual will assist you in diagnosing, analyses, testing, and repair for your mower mid-frame or gasoline engine.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   FH451V
   FH500V
   FH531V
   FH541V
   FH580V
   FH601V
   FH641V
   FH661V
   FH680V
   FH721V

Format: PDF, 181 pages
Language: English
Publication Date: 31 Mar 2006
Table of Contents:
   LIST OF ABBREVIATIONS
   Cylinder Number Designation:
   FH451V, FH500V, FH531V, FH541V, FH580V
   FH601V, FH641V, FH661V, FH680V, FH721V
   Basic Torque for General Fasteners
   Basic Torque for General Fasteners
   Low Idle Speed (Carburetor idle rpm)
   Low Idle Speed (Governor idle rpm)
   High Idle Speed
   Cylinder Head Warp
   Valve Clearance (when cold)
   Valve Clearance (when cold)
   Valve Seating Surface Width (STD)
   Special Tools
   Engine Oil :
   Spark Plug Gap
   High Altitude Main Jet
   Rocker Arm Push Rod Runout
   Valve Head Thickness
   Valve Stem Runout
   Valve Stem Diameter
   Valve Guide Inside Diameter
   Valve Spring Free Length
   Piston Ring/Groove Clearance
   Piston Ring Thickness
   Piston Ring End Gap
   Piston Pin Outside Diameter
   Piston Pin Hole Inside Diameter
   Connecting Rod Small End Inside Diameter
   Piston Diameter
   Cylinder Inside Diameter
   Cylinder Inside Diameter Out Round
   Boring Inside Diameter
   Honing Inside Diameter
   Oil Pressure
   Measurement Condition
   Oil Pressure Switch
   Inner and Outer Rotor Clearance
   Outer Rotor Outside Diameter
   Outer Rotor Thickness
   Pump Housing Inside Diameter
   Pump Housing Depth
   Pump Shaft Outside Diameter
   Pump Shaft Bearing Inside Diameter
   Relief Valve Spring Free Length
   PTO Shaft Bearing Inside Diameter
   Crankshaft Journal Bearing Inside Diameter
   Cam Lobe Height
   PTO Side Camshaft Journal Diameter
   Flywheel Side Camshaft Journal Diameter
   Camshaft Bearing Inside Diameter (Crankcase)
   Camshaft Bearing Inside Diameter (Crankcase Cover)
   Connecting Rod Bend
   Connecting Rod Twist
   Connecting Rod Big End Width
   Crankpin Width
   Connecting Rod Big End Inside Diameter
   Crankpin Outside Diameter
   Crankshaft Runout
   PTO Side Crankshaft Journal Diameter [A]
   Flywheel Side Crankshaft Journal Diameter [B]
   Finishing Dimensional Specifications [FH451V, FH500V, FH531V]
   Finishing Dimensional Specifications [FH541V, FH580V]
   Finishing Dimensional Specifications [FH601V, FH641V, FH661V, FH
   Brush Length
   Commutator Groove Depth Limit
   Commutator Outside Diameter
   Commutator Runout
   Armature Winding Resistance
   Commutator to Shaft Resistance
   Positive Brush to Ground Resistance
   Negative Brush to Ground Resistance
   Regulated Output Voltage
   Stator Coil Resistance (Electric Starter Model)
   Stator Coil Resistance (Recoil Starter Model with Electric Clutc
   Unregulated Stator Output (MIN)
   Ignition Coil Air Gap
   EMISSION CONTROL INFORMATION
