John Deere 860 and 860A Elevating Scrapers Technical Manual (TM1014)

Illustrated factory Technical Manual for John Deere Scrapers Models 860 and 860A.

This manual will assist you in diagnosing, and repairing for your scraper.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   860
   860A

Format: PDF, 448 pages
Language: English
Publication Date: 01 May 1978
Table of Contents:
   Introduction
   General
      Specifications
      Predelivery, Delivery, and After-Sales Services
      Adjustments
      Lubrication
      Separation
   Engine
      Basic Engine
      Cooling System
      Speed Control Linkage
      Specifications and Special Tools
   Fuel System
      General Information and Diagnosis
      Fuel Tank
      Air Intake System
      Specifications and Special Tools
   Electrical System
      Wiring Diagrams
      Charging Circuit
      Starting Circuit
      Air Conditioning System
      Testing Air Conditioning Systen
      Specifications and Special Tools
   Power Train
      General Information and Diagnosis
      Transmission
      Transmission Pump
      Range Selector System
      Torque Converter
      Differential
      Final Drive
      Scraper Axle Assemblies
      Drive Shafts
   Power Steering and Brake Systems
      General Information, Testing, and Diagnosis
      Primary Steering Pump
      Steering Hydramotor
      Steering Control Valve
      Steering Servo
      Steering Cylinders
      Secondary Steering and Brake Pump
      Brake Valve
      Brake Selector Valve
      Accumulator, Valves, Pressure Switch and Filters
      Brake Disks and Shoes
      Parking Brake
   Hydraulic System (Scraper Functions)
      General Information, Testing and Diagnosis
      Hydraulic Pump
      Bowl Control Valve
      Elevator Control Valve
      Elevator Motor
      Hydraulic Cylinders
      Reservoir and Filters
   Miscellaneous
      Elevator Drive
      Elevator
      Steering Arms and Oscillation Hitch
      Sliding Floor Assembly
      Ejector Gate and Bowl
      Operator's Station
      Specifications and Special Tools
