John Deere 1500 Powr-Till Seeders Technical Manual (TM1152)

Illustrated factory Technical Manual for John Deere Powr-Till Seeders Models 1500.

This manual will assist you in diagnosing, and repairing for your powr-till seeder.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   1500

Format: PDF, 42 pages
Language: English
Publication Date: 01 Mar 1977
Table of Contents:
   Introduction
   Safety and You
   General Information
      Description
      Lubrication
   DIAGNOSING MALFUNCTIONS AND TESTING
      Organizing the Diagnosis
      Diagnosing
   POWERSHAFT
      General Information
      Removal and Installation
      Disassembly
      Inspection and Repair
      Assembly
   GEAR CASE AND SLIP CLUTCH
      General Information
      Gear Case
      Slip Clutch
   CUTTER WHEEL UNITS
      General Information
      Removing Line Shaft Assemblies
      Replacing Front Bearing
      Replacing Front Sprocket
      Replacing Rear Shaft Components
      Assembly
   END WHEEL DRIVE.
      General Information
      Axle and Axle Plate Disassembly
      Installation
   GRAIN MODEL DRIVES
      Drive Shaft Replacement
      Inner Bearing Replacement
      Outer Bearing Replacement
      Feed Shaft Bearing Replacement
      Removing Grain Shifter
      Grain Cups
   GRASS BOX DRIVES . .
      Inner Bearing Replacement
      Drive Shaft Replacement
      Outer Bearing Replacement
      Grass Cups
   SPECIFICATIONS
