John Deere 9970 (PIN Prefix 1YC) and China 4MZ-5 Cotton Pickers Repair Manual (TM127319)

Illustrated factory Repair Manual for John Deere Cotton Pickers Models 9970 and China Cotton Pickers Models 4MZ-5.

This manual will assist you in assembling, disassembling, and repairing for your cotton picker.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   9970 (SN: 1YC___)
   China 4MZ-5

Format: PDF, 582 pages
Language: English
Publication Date: 19 Nov 2015
Table of Contents:
   Introduction
      Foreword
   General
      Safety
      General Specifications
      Fuels and Lubricants
   Engine
      Engine
      Cooling System
      Exhaust System
   Fuel and Air Systems
      Air Intake System
      Diesel Fuel System
      Control Linkage
   Electrical
      Batteries
      Starting System
      Charging System
      Monitor and Gauges
      Accessory Circuit
      Connector Repair
   Power Train
      Hydrostatic Drive
      Transmission
      Final Drives
      Control Linkage
   Steering and Brakes
      Steering Column
      Steering Pump
      Steering Cylinders
      Brake and Park Brake System
   Hydraulic System
      Hydraulic Pump
      Solenoid Control Valves
      Picking Unit Lift Cylinder
      Basket Lift Cylinder
      Basket Lid Telescoping Cylinder
      Axle Stabilizer Cylinder
      Hydraulic Motors
      Height Control System
      Hydraulic Reservoir
   Rear Axle
      Guide Wheel Axle
   Operator`s Station Repair
      Air Conditioning System-R134a
      Heating System Components
      Seat
   Picking Unit Lubrication System
      Lubrication System Components
   Water System
      Water System Components
   Air System
      Fan
   Fabricated Tools
      Dealer Fabricated Tools
