John Deere 4LZ-11, 4LZ-11A (C230) Combines (SN: from 010000) (China) Technical Manual (TM128519)

Illustrated factory Technical Manual for John Deere Combines Models 4LZ-11, 4LZ-11A (C230)

This manual will assist you in diagnosing, and repairing for your combine or combine.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (China):
   4LZ-11 C230 (SN: 010000-)
   4LZ-11A C230 (SN: 010000-)

Format: PDF, 643 pages
Language: English
Publication Date: 18 Jun 2021
Table of Contents:
   Introduction
      Foreword
   General
      Safety
      Identification Views and Serial Numbers
      Specifications
      Fuels, Lubricants, and Coolants
      Dimensions
      Delivery and Storage Instructions
   Engine
      Engine Cooling System
      Engine
   Fuel and Air
      Components
      Intake and Exhaust System
   Electrical System
      Battery
      Fuses and Relays
      Operators Station
      Sensors and Switches
      Alternator
      Starting Motor and Starting Relay
   Ground Drive
      Variable Speed
      Clutch
      Transmission and Differential
      Final Drive
   Brakes and Rear Axle
      Brakes
      Rear Axle
      Brake Valve and Brake Fluid Reservoir
   Hydraulic System
      Hydraulic Lines and Connections
      Hydraulic Reservoir
      Hydraulic Pump
      Hydraulic Control Valve
      Hydraulic Cylinders
      Accumulator
      Hydrostatic Motor
   Miscellaneous
      Shafts and Bearings
      Belts
      Chain
   Operator Station
      Cab
      Windshield Wiper
      Operating Platform Levers
      Operator Seat
      Ladder
   Header Repair
      Knife Drive
      Auger
      Reel
      Trailer
   Feeder House
      Feeder House-Removing and Installing
      Feeder House-Adjustments
   Threshing Separation and Grain Cleaning
      Beater
      Cylinder and Concave
      Tine Separator Module
      Tine Separators
      Separator Drive
      Rotor Gear Cases
      Cleaning
      Residue Disposal
   Elevator, Grain Tank and Unloading
      Elevators and Augers
   Electrical Diagnostic
      General References
      Theory of Operation
      Schematics
      Diagnostics
   Electrical Components/Connectors
      Electrical Connectors
   Hydraulic Diagnostics
      Hydraulic System Specification
      Theory of Operation
      Schematics
      Diagnostics
   Hydraulic Components
      Using Instruction
      Symbol Reference
      Hydraulic-A Component
      Hydraulic-C Components
      Hydraulic-F Component
      Hydraulic-G Components
      Hydraulic-M Component
      Hydraulic-O Components
      Hydraulic-P Components
      Hydraulic-R Components
      Hydraulic-V Components
      Hydraulic-X Components
