Hitachi Zaxis 35U-5N (PIN: HCMADG60_ _0270003-) Compact Excavators Repair Manual (TM12924)

Illustrated factory Repair Manual for Hitachi Zaxis Compact Excavators Models 35U-5N.

This manual will assist you in assembling, disassembling, and repairing for your compact excavator.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   Zaxis 35U-5N (PIN: HCMADG60_ _0270003-)

Format: PDF, 346 pages
Language: English
Publication Date: 18 Feb 2021
Table of Contents:
   General Information
      Safety
      Torque Values
   Tracks
      Track System
   Axles and Suspension Systems (Travel)
      Axle Shaft, Bearings, and Reduction Gears
      Hydraulic System
   Engine
      Removal and Installation
   Engine Auxiliary System
      Cooling Systems
      External Fuel Supply Systems
   Dampener Drive (Flex Coupling)
      Elements
   Frame or Supporting Structure
      Frame Installation
      Chassis Weights
   Operator`s Station
      Removal and Installation
      Operator Enclosure
      Seat and Seat Belt
      Heating and Air Conditioning
   Blade (Backfill)
      Blades
      Hydraulic System
   Excavator
      Buckets
      Frames
      Hydraulic System
   Swing or Pivoting System
      Mechanical Drive Elements
      Hydraulic System
   Dealer Fabricated Tools
      Dealer Fabricated Tools
