John Deere 5085E, 5090E, 5090EL and 5100E FT4 Tractors (North American Edition) Repair Manual (TM134519)

Illustrated factory Repair Manual for John Deere Tractors Models 5085E, 5090E, 5090EL and 5100E.

This manual will assist you in assembling, disassembling, and repairing for your tractor.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (North American Edition):
   5085E
   5090E
   5090EL
   5100E

Format: PDF, 566 pages
Language: English
Publication Date: 14 Feb 2022
Table of Contents:
   Introduction
      Foreword
   General Information
      Safety
      General Specifications
      Fuel and Lubricants
      Serial Number Locations
   Engine
      Engine
   Fuel, Air, and Cooling
      Fuel System
      Air Intake System
      Exhaust System
      Cooling System
      Aftertreatment System
      SCR Covers and Shields
   Electrical
      Battery, Starter and Alternator
      Electrical System Components
      Wiring Harnesses
      Connectors
   Drive Systems and Transmissions
      Separation and Clutch Housing
      PR Transmission
      Clutch Assembly
      Differential
      Final Drives
      Rear PTO
      Mechanical Front Wheel Drive
   Steering and Brakes
      Steering
      Brakes
   Hydraulics
      Hydraulic Pump and Filter
      Hydraulic Oil Cooler
      Rockshaft
      Rear Selective Control Valve
      Mid-Mount Selective Control Valve
      Hydraulic Lines
      Hydraulic System Flush
   Miscellaneous
      3-Point Hitch
      Fenders
      Hood
      Step Assembly
      Wheels
   Cab/Operator Station
      Seat and Support
      Control Console and Panel
      Roll-Gard
      Cab Components
      Open Operator Station Components
      Air Conditioning System
      Heating System
   Special Tools
      Dealer Fabricated Tools
