John Deere C670, T550, T560, T660, T670, W540, W550, W650 and W660 MY2008-2011 Combines (SN. from 085500) Repair Manual (TM402619)

Illustrated factory Repair Manual for John Deere Combines with CommandCenter Models C670, T550, T560, T660, T670, W540, W550, W650 and W660.

This manual will assist you in assembling, disassembling, and repairing for your combine.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (MY2008-MY2011):
   C670 (SN: 085500-)
   T550 (SN: 085500-)
   T560 (SN: 085500-)
   T660 (SN: 085500-)
   T670 (SN: 085500-)
   W540 (SN: 085500-)
   W550 (SN: 085500-)
   W650 (SN: 085500-)
   W660 (SN: 085500-)

Format: PDF, 1213 pages
Language: English
Publication Date: 26 Jun 2014
Table of Contents:
   Introduction
      Foreword
   General
      Safety
      Specifications
      Fuel, Lubricants, Coolant and Capacities
   Engine
      Remove and Install Engine
      Lower Engine Repair
      Cooling System
   Fuel and Air Intake Systems
      Air Intake System
      Diesel Fuel System
   Electrical System
      Harness and Connector Repair
      Batteries
      Wiring Harness Routing
      Power Distribution and Location of Control Units
      Switches, Sensors and Motors
      Electromagnetic Valves
      Lighting System
      Operator`s Station
      Wipers
      Alternator
      Starting Motor
      GreenStar Components
   Power Train
      Transmission and Differential
      Final Drive
      Hydrostatic System
      Transmission and Differential for Combines with ProDrive Transmission
      Hydrostatic Motor (Combines with ProDrive Transmission)
      Hydrostatic Pump (Combines with ProDrive Transmission)
      Cam Lobe Motor
      HillMaster II
   Power Steering and Brakes
      Steering
      Brakes
      Brakes (Combines with ProDrive Transmission)
      Wagon Hitch
   Hydraulic System Repair
      Hydraulic Oil Reservoir
      Hydraulic Oil Reservoir (Combines with ProDrive Transmission)
      Hydraulic Pumps
      Hydraulic Pumps (Combines with ProDrive Transmission)
      Hydraulic Valves
      Hydraulic Valves (Combines with ProDrive Transmission)
      Hydraulic Cylinders
      HillMaster II Hydraulic Cylinders
      Motors
      Accumulators
   Separator Shell
      Gull Wing Doors
      Hood - W Series, T Series
      Hood - C Series
   Operator`s Station Repair
      Air-Conditioning System (R134a)
      System Components
      Operator`s Cab
   Feeder House Repair
      Conveyor
      Upper Shaft and Slip Clutch
      Feeder House Drives and Reverser Gear Case
      HeaderTrak Tilt Cylinder and Frame
      HillMaster II Tilt Cylinder and Frame
   Separator - W Series
      Separator Repair
      Cylinder Drives
      Straw Walkers, Crankshafts and Walker Return Pan
      Straw Chopper and Chaff Spreader
      Shoe Supply Augers, Cleaning Fan, Chaffer/Sieve Frame
      Tailings Elevator and Augers
      Primary Countershaft
      Header Electromagnetic Clutch Assembly
   Separator - C Series
      Beaters
      Engine Gear Case to Module Drives
      Tine Separator Module
      Tine Separator Gear Cases
      Shoe Supply Augers, Chaffer and Sieve Frame
      Straw Chopper
   Separator - T Series
      Common Separator Components
      Separator Components and Separator Drive
      Straw Walker Drive
      Remove and Install Beater Grate
      Remove and Install Beater
      Remove and Install Separator Rotor
      Remove and Install Separator Grate
      Remove and Install Overshot Beater
      Remove and Install Stripper Roll
      Remove and Install Slip Clutch for Tailings Elevator and Auger
   Grain Tank and Unloading System
      Grain Tank Cross Augers
      Unloading Auger System Drives
      Vertical Auger and Lower Gear Case
      Horizontal Auger and Gear Case
      Clean Grain Elevator and Loading Auger Gear Case
      Grain Tank and Extensions
   Engine Gear Case and Control Valve, Repair
      Engine Gear Case and Valve
   Special Tools
      Essential Special Tools
      Recommended Special Tools
