Fiat-Allis 3500, 3500 Mark II and 670T Diesel Engines Service Manual (70650824)

Illustrated factory Service Manual for Fiat Diesel Engines Models 3500, 3500 Mark II and 670T.

This manual will assist you in diagnosing, analyses, testing, and repair for your diesel engine.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   3500
   3500 Mark II
   670T

Format: PDF, 204 pages
Language: English
Table of Contents:
   Supplement No. 5 Service Manual Form 70650824 3500, 3500 Mark II, 670T Engines
   Supplement No. 4 Service Manual Form 70650824 (English) 3500 and 3500 Mark II Engines
   Supplement No. 3 Service Manual Form 70650824-6 3500 Engine
   Mailing No. 2 Replacement Pages For 650824 (10-65) Service Manual 3500 Engines Construction Machinery Division
   Mailing No. 1 Replacement Pages For 650824 (10-65) Service Manual 3500 Engines Construction Machinery Division
   Table of Contents
   Description and Specifications
   Cooling System
   Electrical System
   A - Fuel System (With Simms Fuel Injection Pump)
   Air Cleaner and Intake Manifold
   Exhaust Manifold and Turbocharger
   Valves, Valve Operating Mechanism, and Cylinder Head
   Front End and Gear Train
   Flywheel, Ring Gear, Flex Plate Drive, Flywheel Housing, and Crankshaft Rear Oil Seal
   Lubricating System
   Camshaft and Camshaft Bearings
   Pistons, Piston Rings, Connecting Rods, and Connecting Rod Bearings
   Crankshaft and Crankshaft Gear, Main Bearings, and Main Bearing Caps
   Cylinder Block and Cylinder Sleeves
   Engine Removal and Installation
   Engine Disassembly and Assembly
   Fits and Tolerances, Torque Specifications, and Stud Gauge Heights
   Trouble Shooting
   Service Tools
   Conversion Tables
