Flexi-Coil 5000HD Air Drills Repair Manual (87545763)

Illustrated factory Repair Manual for Flexi-Coil Air Drills Models 5000HD.

This manual will assist you in assembling, disassembling, and repairing for your air hoe drill.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   5000HD

Format: PDF, 205 pages
Language: English
Table of Contents:
   GENERAL INFORMATION
      General Service Information
      Important Information
      Service Tools
      Safety
      Units of Measure
      Bolt Torque Information
      Machine Specifications
      Paint Touch-up Procedure
   ADJUSTMENTS
      Air Drill Leveling
      Floating Hoe/Shank Adjustments
      Sweep Pitch Adjustments
      Trip Torque Specifications
      Setting the Depth Gauge
      Wing Lead Adjustment
   MECHANICAL SERVICE
      Troubleshooting Tables
      Servicing Safety Precautions
      General Operating Information
      Grease Locations
      Maintenance
      Tires
      Caster Wheels
      Caster Hub and Spindle Maintenance
      Walking Beam Replacement
      Caster Transport Lock Installation
      Pin Guides
      Depth Control Service
      Walking Beam CarrierSpool Replacement
      Auxiliary Tow Hitch
   HYDRAULICS
      Hydraulics
      Replace Seals in Cylinders
      Hydraulic Cylinders
      Depth Control
      Wing Lift Hydraulics
   ELECTRICAL
      Connector Service Kit
      Remote Switch Installation
   TRIPS, OPENERS, AND PRESS WHEEL SERVICE
      Service of Openers
      Press Wheels and Shanks
      Ground Openers and Seed Boots
      Troubleshooting Tables
      Trip Compressor Tool Kit
      Tension Link Kit - 550 Pound Trip
      Adjustment of Trip Assemblies
      Trip/Shank Shim Installation
      Heavy Duty Bearing Kits
      Press Wheel Removal
      Packer Wheel Rest Assembly
      Shank Spacing and Trip Release Pressure
      Sweep Pitch Adjustment
      Trip Torque Specifications
   AIR SYSTEM
      Troubleshooting Tables
      Hoses
      Theory of Operation - Air System
      Determining Adequate Carrying Velocities
      Header Assemblies
      Hose Holder Brackets and Distribution Clamps
   ENDMARKER SERVICE
      Endmarkers
      Endmarker Replacement
      Endmarker Hydraulics
      Endmarker Operation and Ajdustment
   INDEX
